alkitronic®RCL2 Pneumatic Torque Wrench/Torque Multiplier

alkitronic®RCL2 Pneumatic Torque Wrench/Torque Multiplier

Applications

  • Continuous rotation, tightening, or loosening for all heavy duty fastening connections.
  • Perfect for bolted applications in hazardous, explosive environments.
  • alkitronic® CLS quick, compact torque multiplier for torques of 55 to1,070 ft.lbs.
  • alkitronic® CLD comfortable torque multiplier with rotating handle for torques of 225 to 7,225 ft.lbs.
  • alkitronic® CLS2 high-performance 2-gear machine for torques of 90 to 35,855 ft.lbs.

Advantages

  • Permanently higher joint quality (compared to impact and hydraulic wrenches) by continuous rotation of the square drive.
  • alkitronic® CLD - the 360 degree rotating handle ensures comfortable operation. Barely any reaction forces are transferred to the user. switching to power gear
  • (is used for applying the final torque). alkitronic®
  • CLS2 with fast gear for turning in and simple, quick switching to power gear (is used for applying the final torque).

alkitronic® Specials

  • Simple 1-finger operation for right/left rotation, option to enable thereaction to be locked in one position.
  • Robust cast aluminum housing with proven pneumatic drive.
  • Proven high-performance gears, produced in a chip-free,
  • highprecisionprocess produce high loads with low wear.
  • alkitronic® CLS2 with uniquely high torque - 35,855 ft.lbs.
  • Optional silencer levels to reduce the noise from the motor exhauston request.

Specifications

On request, you will receive our pneumatic multipliers with ATEX-Certification: II 2 G D c IIB T6

Prerequisites for best work with the indicated torques are an operating pressure of 29-10,000 psi at a volume flow of approx. 122-915 cu.in./min. The torque accuracy depends on the stability of the supply system.

Technical Data Models:

Radial Gearing ModelsPneumatic drive

RCL
TypeRCL 36pRCL 80p
Torque range 2nd gear(approx.)     Nm160-470670-1975
Torque range 1st gear (approx.)     Nm500-15001645-4840
Width across flat (AF)                   mm3680
Height (approx.)                 H        mm400450
Width (approx.)                B/B1     mm230/190325/240
Bolt distance (approx.)    A1/A2     mm100/128156/194
Dimensions (approx.)       X/Y        mm56/5698/98
Dimension (approx.)          D         mm9094
Weight (approx.)kg1121
Idle speed 1st gear (approx.)         rpm54
Idle speed 2nd gear (approx.)        rpm1512

*) When loosening a bolted connection, up to 20% higher torque may be required (loosening torque). We will gladly advise you with details.
