Powercom Riganti IR3106 Self-Gripping Clamp

Powercom Riganti IR3106 Self-Gripping Clamp

Made of high tensile alloy steel, hot forged, heat-treated, precision machined and zinc-plated.

  • All Riganti self-gripping clamps comply with European safety standard CE and some are patented designs.

These self gripping clamps or comealong clamps feature machined jaws – they do not have interchangeable jaws (see conductor types listed).

Model NumberIR 3106
WLL (kn)50.0
Interchangeable LinersNo
Weight (kg)7.0
Suitable For (Material Type)Min (mm)Max (mm)
Al, ACSR & Cu7.518.0
Suspension Conductors Al7.518.0
Steel, Earthwire (mm)¹7.518.0
Anti-Twist Braided Rope (mm)¹8.013.0

¹ Square and round steel wires differ in range, contact us for more information.

Please download catalogue page for more details on the Powercom Riganti IR3106 Self-Gripping Clamp.
