THREADER – BALL & RAIL – IPS
THREADER – BALL & RAIL

BALL & RAIL THREADERS (MADE IN CANADA)

The IPs Bull Dawg Rail Threader is robust and designed with high quality bearings and
rollers to ensure long-lasting performance. Available with either square handle for use with
the IPs rail tongs or the triangular, peaked (hook) handle for use with a crane hook. The threaders are designed
to be easily unlocked, opened then dropped over the top of the rail then closed and re-locked.

FEATURES
• Heavy duty rollers
• Manufactured from high-strength steel
• Rugged design for long term, high field
RAIL MATERIAL HANDLING
performance
• Will handle most rail profiles
• Test certified
• Engraved with a serial number
• 5:1 safety factor for lifting

SPECIFICATIONS

Model No. Handle Type WLL (kg) Proof Test (kg) Unit Wt (kg)
2310044C square 5443 7,257 129.3
2310044D Hook 5443 7,257 127.0
Dimensions
Model No. Description (LxW) (mm) Weight (kg)
Replacement pivot bar and roller assemblies to suit
1347 2310044C & 2310044D. Complete with heavy duty rollers, 381 x 102 13.6
bearings and axles.

RAIL THREADER MODEL
NO. HDT-500

At just 43.1kg, the Hound Dawg
rail threader provides heavy-duty
www.specialisedforce.com.au
performance in a comparatively
light and easy to handle unit.
Heavy-duty rollers are designed
with protected bearings for long
term performance.

FEATURES
• Hardened rollers with enclosed bearings for increased durability
• Lifting Bell locks into upright position
• Replaceable heavy-duty rollers & bearings available.
SPECIFICATIONS

Replacement Heavy Duty Rollers & Unit Wt
Model No. Dimensions (mm) WLL (kg) Bearings Model No. (kg)
406 x 381 x 254
HDT-500 (355 with handle raised) 4,535 HDT-500-01 43.1

Replacement rollers are
supplied complete with axle,
bearing, lock washer and nut.
HDT-500-01
