THREADING TONGS & SPREADER BARS – RAIL – IPS
THREADING TONGS &
SPREADER BARS – RAIL

RAIL THREADING TONGS & SPREADER BARS (MADE IN CANADA)

RAIL MATERIAL HANDLING

Model No. LSB-IPS-IU is a spreader bar that features 2 x RH3.3-IPS refer pages 40–41 for tong details only

RAIL THREADING TONG – MODEL NO. VARIOUS
The “Jefferson” Rail Threading Tong is a unique high-performance rail threader
that operates like a conventional rail threader, but has 2 rollers mounted on
each jaw of the tong to allow the rail to thread through the tongs. supplied
with a rounded handle for use with a crane hook.
FEATURES
• Magnetic particle tested
• Load Pull Tested
• Automatically opens when lowered onto rail head
• Replacement roller assemblies available
• Available upon request square handle for use with IPs rail tongs only
2310045A 2310045B
SPECIFICATIONS

Replacement
Model No. WLL (kg) Proof Test (kg) Handle Type Roller Dimensions (mm) Unit Wt (kg)
2310045B 2,721* 4,000 Crane Hook 2310045A-01 317 x 254 x 610 61.8
2310045A 2,721* 4,000 square Handle 2310045A-01 317 x 254 x 610 62.7
www.specialisedforce.com.au
SPARE PARTS

Model No. Description WLL (kg)
2310045A-01 Complete with axles, bearings, lock 9.0
washers and nuts
