PUMPS, HYDRAULIC – LOW PRESSURE – MARUZEN
PUMPS, HYDRAULIC –
LOW PRESSURE

HYDRAULIC LOW PRESSURE PUMPS (MADE IN JAPAN)

MODEL NO. UH SERIES

Low pressure petrol hydraulic pumps for the operation of hydraulic tools and equipment.
FEATURES

• Reliable quality brand petrol driven
engines
• Compact design with folding handle
and pneumatic wheels for easy
manoeuvrability
• Extensive range of tools available to suit
• Equipped with oil cooler which allows
continuous use in hotter climates
• Fitted with standard low pressure male &
female flush face hydraulic couplings
• UH130 three setting oil flow (20-25-30L/
min)
• single tool operation

SPECIFICATIONS

Max. Oil Oil
Model No. Engine (kW) start Max Pressure Flow (L/ Capacity Overall Dimensions Wt
(bar/PsI) min) (L) LxWxH (mm) (kg)
UH070 subaru 4.2 Recoil (Pull) 117 / 1,700 20.5 4.0 615 x 480 x 577 40
UH130-
ELECTRIC Honda GX390/ Electric 137 / 2,000 20.0-25.0- 8.0 800 x 590 x 750 102
START* Robin EX40 9.7 30.0
* Recoil start available upon request
Refer page 99 for hydraulic hose details

FEATURES FEATURES
• Engine petrol driven hydraulic power source • Air Cooled Oil Cooler
• Compact design • Fitted With Male & Female Flush Face Couplers
• Extensive range of tools available to suit • Flip Handle and Pneumatic Wheels for Easy
• Equipped with oil cooler which allows constant use Transportation
even in • Compact and Reliable
hot climates • Large Range of Compatible Tools Available
• Folding handle + pneumatic wheels for easy • Maruzen 30L/min Pump with subaru
maneuverability • Electric start
• Fitted with male & female flush face hydraulic
couplings SPECIFICATIONS

SPECIFICATIONS Model No. UH130
Model No. UH070 Dimensions (mm) 800L x 608W x 650H
Overall Dimension (mm) 615L x 480W x 577H Weight (kg) Dry 95
Weight (kg) 40 Maximum Working 137 (2,000 PsI)
Pressure (Bar)
Engine sUBARU 4.2kW/5.6HP
Oil Flow (L/min) 20-25-30 (3 settings)
Maximum Pressure (Bar) (1,670 PsI)
Engine Type subaru EX40
Max Oil Flow (l/min) 20.5
Oil Capacity (L) 8 litre
Oil Capacity (L) 4
Starter Electric start
Starter Recoil (Pull start)
Refer page 99 for low pressure hoses to suit
