MACHINE, HYDRAULIC –
PUSH-OVER

HYDRAULIC PUSH OVER MACHINE (MADE IN USA)

MODEL NO. 43-000230

For Barring-Over All EMD Locomotive Engines Equipped with Jacking
Pads
The new, improved Model 43 is the “no-sweat” way to bar-over your EMD
engines, reduce your labor requirements and speed up engine inspection and
repair. Piston, Ring, and Liner inspections can be made quickly and easily by one
man.
The Model 43 is a state-of-the-art electronically controlled hydraulic system
designed for high durability and ease of maintenance . The hydraulic manifold
has “quick change” ability incorporated. The plug-in style electrical connectors
and the screw-in style hydraulic components make the Model 43 maintenance
friendly.
FEATURES
• 1.12kW (1.5HP) 137Bar (2,000PSI) Power Unit with 230VAC single phase motor HYDRAULIC TOOLS & EQUIPMENT
• Push-Over Power Head with 9m Supply Lines
• Electrical Control Panel
• Control Pendant attached to Power Unit by 9m Control Cable
• All mounted on pneumatic tired cart for ease of mobility
SPECIFICATIONS

Model No. Hydraulic (Bar) Electric (VAC) Cable Length (m) Motor (kW/HP)
43-000230 700 230/50 9.0 1.12/1.5

HYDRAULIC RATCHET WRENCH (MADE IN USA)

MODEL NO. 60-000230DP

For Loosening, Tightening, and Torqueing Crab Nuts on EMD 567 and
645 and 710 Diesel Engines
This heavy-duty wrench allows for smooth and accurate torque with a range of up
to 4750Nm and maximum breakaway of 5-52Nm. Three torque settings available
are factory at 1220, 2440 & 3250Nm. The mechanic controls the torque by push-
button and does not have to maintain visual contact with the gauges to monitor
stroke or output. The wrench cycles continuously until the selected torque is
reached. At this point the unit shuts off automatically notifying the user that the
crab nut is torqued.

FEATURES
• Hydraulic Ratchet Wrench • Pressure Regulator www.specialisedforce.com.au
• 0.84kW (1-1/8HP) Electrically • Factory Sealed
Driven 700Bar (10,000PSI) • Pressure Relief Valve
Hydraulic Power unit • 7.6m Hydraulic & Electric Supply
• Industrial Controls Lines with Pendant Control
• 18.9L reservoir • 2 Socket Torque Fixtures
• 3 Selectable Pressure Switches • All Mounted on a Pneumatic tyred
• Pressure Gauge Cart for Ease of Mobility
SPECIFICATIONS

Model No. Hydraulic (Bar) Torque Range (Nm) Electric (VAC) Cable Length (m) Motor (kW)
4750
60-000230DP 700 (Max. Breakaway 5-52) 230/50 7.6m 0.84
