WRENCH, HYDRAULIC – RATCHET – TAME
WRENCH, HYDRAULIC –
RATCHET

HYDRAULIC RATCHET WRENCH (MADE IN USA)

MODEL NO. 28-000230DP

For Traction Motor Suspension Bearing Bolts Removal or
Installation on EMD or GE Engines
The Model 70 Hydraulic Ratchet Wrench is a safe and efficient
wrench for Traction Motor suspension Bearing Bolts that reduces
time and effort. savings in labor and locomotive downtime will
quickly repay your investment.
This Wrench offers smooth, controllable hydraulic power that
prevents impact or shock loads, Multiple Torque settings with a
torque range of 270-2160Nm, and precise and repeatable torques to
insure even and accurate tightening of bearings.

FEATURES
• Hydraulic Ratchet Wrench
• Hydraulic Power Unit –0.84kW (1 1/8HP) Electrically Driven HYDRAULIC TOOLS & EQUIPMENT
700Bar (10,000PsI) Power Unit, complete with controls, pressure
gauge, pressure regulator, and factory sealed pressure relief valve
• 7.6m hydraulic hose and control cable
• sockets and swing torque arm for EMD or GE traction motor bearings
• All mounted on a rubber tyred cart for ease of mobility
SPECIFICATIONS

Model No. Hydraulic (Bar) Electric (vAC) Torque Range (kN) Cable Length (m) Motor (kW)
28-000230DP 700 230/50 0.27-2.16 7.6m 0.84
CRAB NUT HYDRAULIC RATCHET WRENCH (MADE IN USA)

MODEL NO. 600-230
Works on all 567, 645 & 710 EMD Diesel Engines

Now the mechanic has one unified wrench to handle all Crab Nuts –
even the hard to fit end spots of the top deck. Once the wrench is
applied the operator simply selects the torque required and holds the
tighten or loosen button. The integrated computer will control torque
and automatically stop on the completion allowing the operator to
move to the next location.
FEATURES
• Compact Design with 20% more available power
• Hydraulic Ratchet Wrench www.specialisedforce.com.au
• 0.84kW (1-1/8HP) Electrically Driven 700Bar (10,000PsI) Hydraulic
Power unit
• Industrial Controls
• 18.9L reservoir
• 3 selectable Preset Adjustable Torque settings (3250, 2440 &
1220Nm)
• 7.6m Hydraulic & Electric supply Lines with Pendant Control
• Pressure Regulator, Gauge, Factory seal Pressure Relief valve
SPECIFICATIONS

Model No. Hydraulic (Bar) Electric (vAC) Cable Length (m) Motor (kW)
600-230 700 230/50 7.6 0.84 (1-1/8HP)
