BLOWING EQUIPMENT – HEARTHILL
BLOWING EQUIPMENT

ELECTRIC BLOWER KIT

This high volume, low pressure blowing system
is used to blow a balloon type bag attached to BLOWING
a draw line or string down a conduit. The draw DISTANCE Blow
line is then used to pull a heavier hauling rope 1,000m into 15-
back to your start position. This system can 160mm Conduit
easily rope a 100mm conduit 300-500 metres.
Dual stage motors, 230vAC/50Hz Electric Power (Empty)
Blower. 1300W delivering approximately 3.5
cubic metres of air per minute.

EBK2-130K KIT INCLUDES:
Model No. DEsCRIPTION
1 x Blower EBk2-1300
EBK2-130K Complete Blowing kit
5m x 50mm hose EBP-5M50 EBK2-1300 Blower Unit Only (11.9kg)
1 x Hand-Gun EBH-30
1 each Conduit seal-Offs Refer below table for sizes

Model No. DEsCRIPTION
ECS-12 Conduit seal off for 12 to 40mm
ECS-50 Conduit seal off for 40 to 70mm
ECS-110 Conduit seal off for 70 to 160mm

1 each Rope grommets 3mm, 5mm and 7mm

CRB SERIES CONDUIT ROPE BLOWER

This pneumatic conduit seal off was designed so to eliminate the need for multiple size seal off plugs, the
tapered head for allows use on 40-150mm conduit (170mm at largest point so suitable for 150mm conduit
bell end). suitable for blowing 6mm Tesltra rope (Parramatta) on longer runs or jet line or twine on smaller
runs. Made from 316 grade stainless steel with solid polyurethane cone. It requires a large compressor to
operate (2.1cm3 75 CFM minimum) with 3/4” Claw Air Fitting (Minsup A). CRBA-125 has an angled end to
tight spots or pits.

Model No. suits Conduit (mm) Length (mm) Weight (kg)
CRB-150 50-150 630 4.1
CRBA-125 40-125 550 3.2 CRBA-125

SCAN
& PLAY
CRB-150

ACCESSORIES

BALLOON LINE CARRIERs, CONDUIT sEAL OFFs and COMPREssOR BLOWERs also available.
