SHEAVES, BELLMOUTHS & GUIDES – CONDUIT fEEDING –
HEARTHILL
SHEAVES, BELLMOUTHS &
GUIDES – CONDUIT fEEDING
ALWAYS
fEEDING SHEAVES & GUIDES MEASURE
CONDUIT
ELECTRICAL, WINCHES, STRINGING & CABLE LAYING
ID Australian Made
Conduit Nom. Approx Equip
Image Model No. * Dimensions (mm) Weight (kg)
OD (mm) OD (mm)
IfS-050E 255 X 120 X 115 50 42 1.60
IfS-050T 255 X 130 X 115 50 48 1.60
IfS-063E 255 X 140 X 115 63 48 1.60
IfS-063T 250 X 155 X 110 63 60 1.70
IfS-080 250 X 200 X 140 80 74 1.80
IfS-100 250 X 220 X 155 100 98 2.80
IfS-125 250 x 240 x 165 125 118 3.20
IfS Series IfS-150 250 x 260 x 175 150 138 4.40
fS-050E 370 X 160 X 180 50 38 2.90
fS-050T 380 X 160 X 180 50 48 3.30
fS-063E 380 X 160 X 180 63 48 3.30
fS-063T 380 X 160 X 180 63 60 3.30
fS-080 370 X 170 X 200 80 74 3.50
fS-100 390 X 190 X 210 100 98 5.60
fS-125 390 X 200 X 220 125 118 6.10
fS-150 400 X 230 X 230 150 138 6.40
fS Series fS-200 460 X 280 X 320 200 190 13.90
fS-080-4R 360 x 200 x 170 80 74 5.20
fS-100-4R 380 x 220 x 180 100 98 6.50
fS-125-4R 390 X 230 X 260 125 118 7.00
fS-150-4R 390 X 260 X 280 150 138 7.90
fS-***-4R Series
fS080-4A90 900 X 620 X 260 80 74 12.20
fS100-4A90 900 X 620 X 260 100 98 15.00
fS125-4A90 900 X 620 X 260 125 118 15.00
fS150-4A90 900 X 620 X 260 150 138 15.00
fS200-4A90 900 X 620 X 260 200 190 23.80
www.specialisedforce.com.au
* “T” for Telecommunications Conduit or “E” for Electrical Conduit
CS & CLS SERIES STANDARD & LOCKABLE CONDUIT SLIPPER GUIDE
Cable slippers cables from sharp corners of conduit during laying. They are robust and economical with much
thicker material than the cheaper versions on the market. Zinc plated finish. CLS series are lockable.
Conduit Nom. Approx Equip
Model No. * Dimensions (mm) Weight (kg)
OD (mm) OD (mm)
CS-050E 310 X 50 X 85 50 42 0.50 qUALITY
CS-050T 310 X 50 X 85 50 48 0.50 THICK
CS-063E 310 X 50 X 85 63 48 0.50
CS-063T 310 X 50 X 85 63 60 0.50 STEEL
CS-080 465 X 90 X 150 80 74 1.30
CS-100 560 X 110 X 180 100 98 2.50
CS-125 720 X 140 X 230 125 118 4.90
CS-150 750 x 160 x 250 150 138 5.30
CLS-050E 310 x 130 x 150 50 38 1.20
CLS-050T 310 x 130 x 150 50 48 1.20
CLS-063E 310 x 130 x 150 63 48 1.20
CLS-063T 310 x 130 x 150 63 60 1.20 CS Series CLS Series
CLS-080 410 x 160 x 250 80 74 2.50
CLS-100 550 x 190 x 340 100 98 4.60
CLS-125 680 x 220 x 410 125 118 6.80
CLS-150 720 x 250 x 450 150 138 7.20
* “T” for Telecommunications Conduit or “E” for Electrical Conduit
