CUTTERS – REMOTE HYDRAULIC – IzUMI
CUTTERS – REMOTE HYDRAULIC

REMOTE HYDRAULIC CUTTNG HEADS (MADE IN JAPAN)
ELECTRICAL, WINCHES, STRINGING & CABLE LAYING
MODEL NO. SP & P SERIES

Remote heads are for fast cutting action and allow remote operation manoeuvrability into tight areas. These
guillotine style cutting heads jam less than scissor shear type cutters and have spring return rams. The head can
be operated by any hydraulic pump with rated oil pressure of 700 Bar. The blades are easily replaceable and the
head is a snap lock spring release on smaller models and lock pin type on larger capacity heads.

SP-20A SP-24 SP-32 SP-40A SP-55A P-60 P-85 P-132
Remote heads supplied with soft case and screw type female coupling # 3050-3 standard

fEATURES
• Easy to replace blade
• Spring return ram
• quality ISO9001
SPECIfICATIONS

www.specialisedforce.com.au
Al
Cu
ACSR
Latch
Comms
Soft Steel
Guy Wire*
Wire Rope
Model No.
Wteight (kg)
Max Ø (mm)
Rebar (650Mpa)
Hyd Pressure (bar)
SP-20A Snap 20 20 20 20 15-16 16-20 16 (400 to 500Mpa) ReBar 10 20 700 2.75
13
SP-24 Snap 24 24 24 24 20 18-24 20 16 12.4 24 700 3.10
SP-32 Snap 32 32 32 32 32 32 25 25 15.5 32 700 3.10
SP-40A Pin 41 41 41 38 15-20 22-25 20 16 12.4 41 700 5.00
SP-55A Pin 55 50 50 50 15-20 25-30 22 19 12.4 55 700 6.90
P-85 Pin 85 28** 38** - - - - - - 85 700 5.00
P-60 Pin 60 60 60 - - - - - - 60 700 2.75
P-132 Pin 132 100 130 - - - - - - 132 700 6.40
* Contact us for more detailed information on Guy Wire capacities as stranding affects capacity where range is displayed
** Will cut AL & CU strands up to 85mm OD depending on cable type. Please contact Specialised Force for more information.

Refer page 107–108 for hydraulic pumps details
