CUTTERS – HAND HYDRAULIC – IzUMI
CUTTERS – HAND HYDRAULIC

HAND HYDRAULIC CUTTERS (MADE IN JAPAN)

MODEL NO. S SERIES

Hand operated hydraulic cutters for cables, conductors and many capable of steel up to Rebar. These guillotine
style cutting heads jam less than scissor shear type cutters and have spring return rams. The blades are easily
replaceable and the head is a snap lock spring release on smaller models and lock pin type on larger capacity
heads.

ELECTRICAL, WINCHES, STRINGING & CABLE LAYING

S-200 S-240 S-320 S-400 S-550 850 S-240CC S-32CC1
Cutters supplied with case
fEATURES

• Easy to replace blade • Swivel head (excluding suffix CC/CC1)
• Spring return ram • Models with suffix CC & CC1 have special anvil shape
• Some models feature safety relief valve blades for solid material
• Some models feature two stage pumping • Rubber grip handles
• quality ISO9001

SPECIfICATIONS

Al
Cu
Latch
ACSR
Comms
Cuts Max
Soft Steel
Guy Wire*
Model No.
Wire Rope
Weight (kg)
Max Ø (mm)
Rebar (650Mpa)
1
13
-
S-200 Snap Rebar Pump Stages 20 20 20 20 16 16-20 16 (400 to 500 Mpa) ReBar 10 Chain (Gr80) 20 3.0
S-240 Snap Rebar 1 24 24 24 24 20 18-24 16 20 12.4 - 24 4.9
S-320 Snap Rebar 2 32 32 32 32 32 32 25 25 15.5 - 32 10.8
S-400 Pin Rebar 2 41 41 41 38 15-20 22-25 20 16 12.4 - 41 5.9
S-550 Pin Rebar 2 54 54 54 54 15-20 25-30 22 20 13 - 54 9.3
850 Pin Cu/Al 2 85 28 38 - - - - - - - 85 8.1 www.specialisedforce.com.au
S-240CC Snap Chain 1 16 - - - 16 - 16 16 9 6 - 5.0
S-32CC1 Snap Chain 1 25 - - - 20 - 19 25 15.5 12 - 10.2
* Contact us for more detailed information on Guy Wire capacities as stranding affects capacity where range is displayed

Snap Latch Pin Latch
