POWER UNITS – DIESEL – DURAPAC
POWER UNITS – DIESEL

DIESEL DRIVEN RAILWAY POWER UNITS

THE PDM3054-RAIL DIESEL DRIVEN RAILWAY POWER
UNIT IS SUITABLE FOR heavy duty APPLICATIONS IN THE
FIELD and can deliver a minimum flow of 2.5 Lpm at 700 bar pressure.
It is specifically designed to operate rail tensors and weld shears commonly used in the railway industry. It
features a selector valve to choose which tool to operate and individual directional control valves for each tool.
Tools can be single or double acting and each tool may have a different maximum operating pressure.

FEATURES
• MOTOR sIZE - 3.4 kW
• FLOW - 2.5 Lpm
• Maximum Operating
Pressure - 700 bar TENsOR OUTLET

WELD sHEAR OUTLET
sELECTOR vALvE
PUMP, DIEsEL HIGH PREssURE choose between tensor or weld shear

Flow Rate Maximum valve Types
Motor Usable Oil Approx. Dry Approx. Dimensions
Model Number kW rpm (Lpm) @ Pressure (3/8"-NPTF
Type Capacity (L) Weight (kg) (mm)
700 bar Rating (bar)* Ports)
selector
PDM3054-RAIL Diesel 3.4 2,200 2.5 700 shear** 50 190 450 W x 750 L x 650 H
Tension**
* specify tool working pressure at placement of order.
** specify single or double acting tools at placement of order.
