WELD SHEAR – RAIL –TRUFLAME
WELD SHEAR – RAIL

RAIL WELD SHEARS (MADE IN UK)

MODEL NO. TCRSS&S

This ultra-lightweight hydraulic rail shear
is designed for the removal of excess
material after the procedure of Thermit
rail welding of two rail sections. It leaves
a sufficient amount of material for final
grinding. The modern design of this unit
uses two x 15 tonne (30 tonne in total)
high pressure spring return cylinders
which operate at up to 700Bar. The
unit is supplied with a cutting blade set
suitable for 53/60/68kg rail profile.
The unit consists of three major
assemblies: frame with rail clamps,
hydraulic cylinder group with blade set WELDING, GRINDING & BENDING
& choice of hand, electric, battery, air or
petrol pump (sold separately).
OPTIONAL POWER OPTIONS

3m High Pressure Hand Pump High Electric 230vAC Pump High
10,000PsI Hydraulic Hose Pressure Hydraulic Pressure 10,000PsI with Hand Petrol Pump High Pressure
with Couplers 10,000PsI Control (Adv/Hold/Ret) 10,000PsI with Roll Frame
sF DURAPAC DAIA DURAPAC
HPS-0603DR P-2200 DSP-120 PPM2014
Note: The hydraulic cylinder group weighs 35kg and has a lifting handle (for ease of handling) to remove or
replace the group. It simply drops into position.
FEATURES
• Easy & effortless • Ideal for switches and crossing
• Lightweight at 63kg • Cutting blades included (53/60kg)
SPECIFICATIONS

Operating Weights (kg)
Model No. Pressure Rail Capacity* Frame with Rail Hydraulic Cylinder Weight www.specialisedforce.com.au
(Bar) (kg) Clamps Group with Blade set Pump set (kg)
TCRSS&S 700 53 & 60 28 35 ** 63
* Up to 68kg rail available upon request
** Refer to pages 106–108 for available pump options
REPLACEMENT PARTS
Replacement Blades Model No.
TCRSS-BLADE

Approved by British Rail (Cert. No. PA05/3762)
