BENDER – HYDRAULIC – ALDON
BENDER – HYDRAULIC

HYDRAULIC RAIL BENDER

MODEL NO. 4021-01

Bend 30-60kg/m rail for switch point pockets and rail repairs. For full kit with bending head, hand pump and hose
refer to the below specifications for “bender head” as well as “pump & hose” as components to make the full kit
are sold separately.
WELDING, GRINDING & BENDING

FEATURES
• 30 tonnes of Bending Force
• Heavy Duty Cast Bending Frame
• Hydraulic cylinder has Hard Chromed Piston and Internal Bore to Resist Rusting and pitting

SPECIFICATIONS
BENDER HEAD

www.specialisedforce.com.au
Wt
Force
Model No. Description Rail Capacity Power source (Tonne) (kg)
(kg/m)
Remote bender head package includes; 700bar Hydraulic Pump
4021-01 - Bending Head Frame 30-60 Required (Refer below) 30 83.6
- Riken 30T Jacking Cylinder (#sJ3-125)
PUMP & HOSE

Model No. Item Description Rated Pressure (Bar) Wt (kg)
P4 Pump Riken Hand Pump, 2 speed, Integrated safety 700 11.5
valve, 1,800cc Useable Oil
HPS-0602ER Hose Durapac 2 metre high pressure hose with CEJN 700 1.5
safety speed coupling one end
