WRENCH – PETROL IMPACT & CARRIER – AIRTEC
WRENCH – PETROL IMPACT &
CARRIER

PETROL IMPACT WRENCH (MADE IN EUROPE)

MASTER35 CARRIER - MODEL NO. 1750 SERIES

DRILLS, SAWS & IMPACT WRENCHES
Designed for use with the Master 35 Petrol Impact Wrench and other tools. The MASTER35 carrier is fitted with a
simple but effective dead man handle braking system. The brake wheel has three locking positions for additional
safety.
Using the Master Carrier reduces manual handling, makes it easier and quicker to use equipment, improves
operator comfort and increases productivity.

It is made up of three main parts- Main Frame, Cross Bar and Wheel Assembly and can be easily assembled in a
few minutes. Each part is small and light enough to be carried manually or transported in a car or small van.
There are two optional accessories which allows the Master to be used in a vertical or horizontal position for
Screw Spikes, removing/fitting Fishplate/Joint Bar fasteners and removing rusty clips.

DEADMAN
BRAKE
SUPPLIED
STANDARD
SCAN
& PLAY

SPECIFICATIONS

Approx. Weight Dimensions Assembled
Model No. Description
(kg) LxWxH (mm)
1750.0090-B Carrier – Narrow Gauge 1067mm 35.8
1750.0100-B Carrier – Standard Gauge 1435mm 30 1080 x 1625 x 870 Open
www.specialisedforce.com.au
(440 locked)
1750.9999-B Carrier – Broad Gauge 1600mm
OPTIONAL ACCESSORIES

Model No. Description
2801.7560 Hook Assembly for horizontal use
2801.7550 Wrench Bracket for vertical use
Narrow Gauge to standard Gauge
2801.7520 & Broad Gauge to standard
Gauge Bar 1435mm
Narrow Gauge to Broad Gauge &
2801.7525 standard Gauge to Broad Gauge
Bar 1600mm
2801.7535 Wheel Assembly standard Gauge
& Broad Gauge to Narrow Gauge
2801.7515 Bar 1000mm standard Gauge &
Broad Gauge to Narrow Gauge
2801.7530 Wheel Assembly kit with Handle
for standard & Broad Gauge
28004800 safety Locking knob for Carrier

Model No. 28004800
28004800 Safety
Locking Knob Safety locking card and knob for positive
engagement of the holding the arm
