RAIL SAW – ACCESSORIES & KIT – HUSQVARNA
RAIL SAW – ACCESSORIES
& KIT

PETROL RAIL SAW OPTIONS & ACCESSORIES

RA10 & RA10S 04419 & 04415 505698001 5444502-02
Model No. Item Part No. Wt (kg) Specifications Description

506226611 Rail RA10 5.5 suits Rail >68kg The Husqvarna RA10 and RA10s attachments for
Attachment (standard) the cutter k1270 Rail have zero-play needle and ball DRILLS, SAWS & IMPACT WRENCHES
bearings. Fits quickly to the rail and provides right-
angle cuts on all levels. A folding guide marks the exact
Rail position of the cut
506226612 RA10S 5.8 suits Tram Rail
Attachment (RA10 supplied standard with k1270 purchase, RA10s is
an optional extra)
Ø 350mm (14”) Trak-star cut-off discs are designed for the demanding
04419 Cut-Off Disc - 1.4
suits k1270/14 process of cutting all types of railway line. Double
sided fibre reinforced ensures a straight cut every time.
Wears evenly & consistently, making it less vulnerable
Ø 406mm (16”) to glazing when cutting through head-hardened rail
sections. Specifications;
04415 Cut-Off Disc - 1.4 suits k1270/16 & - 25.4mm (1”) centre hole
Hs16
- 3.2mm thick, 5,400RPM Maximum
(standard pack size is 10 discs)
Husqvarna Petrol Container with overfill protection.
When the tank is full the flow is automatically shut
Petrol
505698001 Container - 0.9 6L Capacity off and you can lift the container up without spilling.
Features date stamp on the bottle.
5444502-02 Oil - 1.1 2-stroke (1.0L) Husqvarna 2-stroke oil comes in a 1.0L bottle
Husqvarna kit Contains: Air Filter, Belt, Fuel Filter, spark
K1270-16SKIT service kit - 1.3 - Plug & starting Cord
Refer below for more details

MODEL NO. K1270/16SKIT (589-40-47-07)

SCAN
& PLAY

Service Kit Contents www.specialisedforce.com.au

Ref Product Description Model Number qty
A Air Filter 510 24 41 03 1 Generic Model
B Belt 544 97 63 01 1 Shown
C Fuel Filter 506 26 41 11 1
D spark Plug 503 23 51 09 1
E starting Cord 506 33 56 15 1
