PULLER/EXPANDER – RAIL
GAUGE

RAIL GAUGE EXPANDERS/PULLERS (MADE IN CANADA)

These expander and puller tools were designed for correcting rail gauge. A great tool for
rail change out applications or restoring gauges quickly and easily. Also useful in derailment areas and holding
gauges during tie renewal programs. Application can be from the base of the rail (Model No. 2310030A) or either
base and top of the rail (Model No. 2310030B). TEST, MEASUREMENT & DYNAMOMETERS

Track
Model No. Alignment Suits Gauge* Bracket Suits Rail Insulated Dimensions Weight (kg)
(Base/Top) Ends* (kg) (Yes/No) (mm)
Narrow
2310030A-N Base 1067mm 2 x Single 41-60 No 51x65x1160 8.7
Sided
2310030A Base Standard 2 x Single 41-60 No 51x65x1524 9.1
1435mm
Sided
Broad
2310030A-B Base 1600mm 2 x Single 41-60 No 51x65x1765 11.5
Sided
Narrow
2310030B-N Base or Top 1067mm 1 x Single & 41-60 No 51x65x1160 17.5
1 x Double
Sided
1 x Double
2310030B Base or Top Standard 1 x Single & 41-60 No 51x65x1524 18.7 www.specialisedforce.com.au
1435mm
Sided
Broad
2310030B-B Base or Top 1600mm 1 x Single & 41-60 No 51x65x1765 20.1
1 x Double
Sided
Narrow
2310030D-N Base 1067mm 2 x Double 41-60 Yes 51x65x1160 18.4
Sided
2310030D Base Standard 2 x Double 41-60 Yes 51x65x1524 19.6
1435mm
Sided
Broad
2310030D-B Base 1600mm 2 x Double 41-60 Yes 51x65x1765 22.0
Sided
* Rail spreaders are available with single and double sided ends, double bracket ends are used for turn outs
