PULLERS & SPREADERS – TRACK – ALDON
PULLERS & SPREADERS – TRACK

RAIL PULLER “RAILPULL” (MADE IN USA)

MODEL NO. 4023-74
TEST, MEASUREMENT & DYNAMOMETERS
The RailPull rail puller from Aldon brings rail back into gauge after a derailment so rerailing can proceed. Cars can
temporarily pass over Rail Pull saddles until rails can be re-gauged. You can use a 1/2” sq. dr. ratchet wrench and
1/2” sq. dr by 1” 8-point impact socket for the securing bolts.
FEATURES
• Solid formed plate 12.7mm steel
• no welded joints to crack
SPECIFICATIONS

Model no. Wt (kg)
4023-74 35

TRACK GAUGE SPREADER (MADE IN USA)

MODEL NO. 4023 SERIES

Grabs rail head or base to pull or push rails into desired
gauge. Can be used in both regular track and within
switches. one end of the head-of-rail Spreader model
has a double jaw, one of which is offset to lift Spreader
above switch point or heel block. Gauging range 406mm.
Reversible ratchet wrench with flip key to change
movement direction. Useful for correcting track after
derailment and when installing gauge rods. 4023-50 Head
of Rail is shown in the image on the right.
www.specialisedforce.com.au

Model no. Description Gauging Range (mm) Wt (kg)
4023-50 Head of Rail (non-Insulated) 406 10.9
4023-51 Base of Rail (non-Insulated) 406 10.9
4023-52 Base of Rail (Insulated) 406 10.9
