TAPER GAUGES & THERMOMETER – MAGNETIC – STARRETT
TAPER GAUGES &
THERMOMETER – MAGNETIC

RAIL TAPER GAUGES (MADE IN USA)

MODEL NO. 4124-98

4124-98

SPECIFICATIONS

Model No. Features Specifications Unit Wt
(kg) TEST, MEASUREMENT & DYNAMOMETERS
very useful tool for bearing work and for gauging Range (“): 010-.150”
slots. Made of quality tool steel and accurately tapered Range (mm): 0.3-4
throughout entire length for quick and convenient Graduations (“): .001”
4124-98 measuring. Can be used as a precision shim. One side Graduations (mm): 0.05 Less 0.5
graduated from 0.010” to 0.150” in thousandths of an Length x Width (mm): 160
inch; the reverse side from 0.3mm to 4mm in one- x 11
twentieth of a mm (0.05mm).
MAGNETIC RAIL THERMOMETER (MADE IN USA)

MODEL NO. PTC SERIES

PTC312CRR PTC314CRR
-20°C to +120°C +10°C to +400°C
Quality magnetic thermometer with Celsius gauge type display. Certification of temperature available upon
request at additional charge.
SPECIFICATIONS

Model No. Features Temperature Range (°C) Unit Wt (kg)
PTC312CRR Measurement of -20°C to +120°C 0.043
PTC314CRR temperature in °C +10°C to +400°C 0.057 www.specialisedforce.com.au
