RAIL CHOCK – URETHANE, HEAVY-DUTY, SPARK-PROOF – ALDON
RAIL CHOCK – URETHANE,
HEAVY-DUTY, SPARK-PROOF

SPARK-PROOF HEAVY-DUTY URETHANE RAIL WHEEL CHOCK

sPARk-PROOF Urethane Wheel Chocks are tough enough to block a
tank car, but resilient enough that the car can be pulled over the chock
by a locomotive without derailing. For chocking tank cars and other
freight cars, loading or unloading hazardous materials and used where
a spark from a steel wheel chock could ignite dust or fumes.
No more trying to yank free a steel chock that
is stuck under a wheel. When it’s time to move,
just pull the car over the chock and retrieve
the chock later. Moulded transverse ribbing SPARK
squeegees out water and dirt from rail surface,
to increase holding power. Urethane has great resistance to loads with the ability to FREE
compress to half of its thickness and then spring back to its original shape. Urethane will
not degrade from corrosive materials and most chemicals.

When installed on flush rail the handles are 38mm above the pavement for easy gripping. LOCOMOTIVES & RAIL CAR STOPPING DEVICES
Watch the video of the successful test at the Association of American
Railroad’s testing facility at Pueblo, Colorado and then at a shortline
SCAN railroad.
& PLAY
Refer to the scan and play for this and other related product
information.

SINGLE - For one direction

Model No. Rail Type Wt (kg) Model No. Rail Type Wt (kg)
4011-42 Exposed 2.3 4011-43 Flush 2.3

DOUBLE - Designed for two way direction, handles are 610mm long, with elastic linking lanyard.

Model No. Rail Type Wt (kg) Model No. Rail Type Wt (kg)
4011-40 Exposed 4.1 4011-41 Flush 4.1

WARNINGS! www.specialisedforce.com.au
1. For use on flat track only. Do not use chocks on grades.
2. Set brake before installing chocks. Rail car or locomotive must be stopped and brakes applied before
chocks can be placed.
3. Do not use chock if rail car or locomotive is lifted up at one end for inspection or repair.
4. Chock both ends of the rail car or locomotive.
5. Use on rails 44.6 to 76.9kg/m.
6. Minimum wheel diameter 838mm (33”).
7. Do not use on oily or greasy rail as chock will slide.
8. When rail car is ready to be moved, you may pull car over chocks. They will return to their original shape.
9. Replace chocks if urethane is torn or cracked.
