LOW PRESSURE CRIMPER – 12T

MODEL No. LP-430C/FF

LOW PRESSURE 12 TONNE CRIMPER

SAFETY TRIGGER

A CABLE CRIMPING FORCE FREE PISTON
12 Tonne Type

JAW OPENING
36mm C-HEAD
CAPACITY
300mm2 Al/Cu
PINCH
Standard 12 ton Dies
Nest/Indent & “C” connector Dies
DESIGN

SPECIFICATION
• Low pressure hydraulic compression tool
Model No.
• Direct power input from truck PTO
Ram Stroke LP-430C/FF DETAILS
36mm (Jaw opening)
• Relief setting at 140 Bar
Force at die face 110 kN • Suitable for EWP
Size 127 (dia) x 557 (l) mm • Covered handle & trigger guard
Weight 8.25 kg • Dies are sold separately
Refer pages 18–20 for 12T Dies
www.specialisedforce.com.au
FEATURES **NOTE Also Available
MODEL No. LP-430CPB
The LP-430C/FF hydraulic tool is directly Polyurethane Hand block, to Minimise
powered by PTO (Power Take Off) from EWP “PINCH POINT” of ram
(Elevated Work Platform) or any vehicle with
a low pressure hydraulic circuit having oil
pressure of 140 Bar and maximum flow of 35
litres/min.
The LP-430C/FF is designed to operate with either
Open-Centre or Closed Centre hydraulic system by
rotating the head to the Correct Setting.
The LP-430C/FF has the same compression head
as the EP-430 so that dies are interchangeable with
all 12 ton U-type dies industry standard dies can be
used.
Features an in-built relief valve pre-set at 140Bar to Safety Trigger alleviates tool being
prevent tool overload. operated accidently
