REMOTE HEAD CRIMPER –
12/15T

REMOTE HEAD CRIMPER 12/15 TONNE

TEP-410HB EP-H130H EP-610HS2
FITTED WITH A RUBBER BOOT FOR
ADDED ELECTRICAL PROTECTION

REMOVEABLE END BLOCK
FORCE FORCE FORCE
12 Tonne Type 3.3KG 12 Tonne Type 15 Tonne Type
JAW OPENING TITANIUM JAW OPENING MAX JAW OPENING MAX
25mm MAX 28mm 300mm 2 40mm with 630mm 2
CAPACITY 300mm 2 CAPACITY dies fitted
300mm² Al/Cu 300mm² Al/Cu CAPACITY
Standard 12 ton Dies Standard 12 ton Dies 300mm² AL & 400mm² CU* Or
Nest/Indent & “C” connector Dies Nest/Indent & “C” connector Dies 500mm² AL & 630mm² with
15T Dies A CABLE CRIMPING
MODEL No. TEP-410HB MODEL No. EP-H130H * Accepts 12T Dies with
Adaptor
INCLUDED ITEMS INCLUDED ITEMS MODEL No. EP-610HS2
Crimp Head, Steel carrying case Crimp Head, Steel carrying case
with die tray with die tray
INCLUDED ITEMS
SPECIFICATION SPECIFICATIONS Steel carrying case with die tray
Accepts existing 12 ton Standard
Dies
Ram Stroke 25mm Ram Stroke 28mm Nest/Indent & “C” connector
(Jaw opening)
(Jaw opening)
Oil volume require 42 cc Oil volume 51 cc Dies when used with 15T-PU-
ADAPTOR
Force at die face 106kN required Will crimp up to 500 mm AL &
Dimensions 340 (l) mm Force at die 120kN 630mm CU by purchasing special
Weight 3.3 kg face Dies
Size 317 (l) mm
FEATURES Weight 4.1 kg SPECIFICATIONS
The TEP-410HB is a lightweight FEATURES Ram Stroke 50mm
(Jaw opening)
remote C-head that requires
an external 700BAR or The EP-H130H is a H-head Oil volume 100 cc
required
10,000 PSI pumping source with a 28mm jaw opening. It
for operation. This unit is accepts all shell type dies and Force at die face 139kN
manufactured from titanium, dies for deep indent crimps Size 375 (l) mm
which makes it significantly currently used in 12 ton tool on Weight 7.0 kg www.specialisedforce.com.au
lighter than comparable cast today’s market.
steel compression heads. A 700 BAR external pump is FEATURES

This tool was designed to required to operate The EP-610HS2 is a remote
accommodate 12 ton dies for this tool. C-head that requires an
applying compression fitting to external 700 BAR or 10,000 PSI
copper, aluminium, and ACSR DETAILS pumping source.
conductor. • Dies are sold separately
Refer pages 18–20 DETAILS
for 12T Dies
• Dies are sold separately.
Refer pages 18–20 for 12T
Dies & page 8 for 15T Dies
• Refer page 116–117 for hydraulic coupling configurations and hoses,
supplied standard with screw type female 3050-3 coupling
• Battery or Electric pumps, refer page 106 to 112
