REMOTE HEAD CRIMPER – 12T







          REMOTE HEAD CRIMPER 12 TONNE






                                                                                EP-510HE
            EP-431HA
                                                                                 FITTED WITH A RUBBER BOOT FOR ADDED
                                                                                 ELECTRICAL PROTECTION






            FORCE                                                                FORCE
            12 Tonne Type    300mm     2       FORCE           300mm     2       12 Tonne Type   400mm     2
                                                                                                   MAX
                                MAX
                                                                 MAX
      A   CABLE CRIMPING  MODEL No. EP-431HA  MODEL No. EP-410HF               MODEL No. EP-510HE
                                               12 Tonne Type
            JAW OPENING
                                                                                 JAW OPENING
            31mm C-HEAD
                                                                                 42mm C-HEAD
                                               JAW OPENING
                                               27mm
            CAPACITY
                                                                                 CAPACITY
            300mm² Al/Cu
                                                                                 300mm² AL & 400mm² CU
                                               CAPACITY
                                               300mm² Al/Cu
            Standard 12 ton Dies
                                                                                 Standard 12 ton Dies
            Nest/Indent & “C” connector Dies
                                                                                 Nest/Indent & “C” connector Dies
                                                                               INCLUDED ITEMS
                                             INCLUDED ITEMS
          INCLUDED ITEMS
          Crimp Head, Steel carrying case
                                             Remote Head Crimper & Metal
                                                                               Crimp Head, Steel carrying case
          with die tray
                                                                               SPECIFICATION
          SPECIFICATION
                                             SPECIFICATIONS
                                                                                   Ram Stroke
                                                Ram Stroke
              Ram Stroke     31mm            Carry Case.       27mm            with die tray     42mm
                                                               (Jaw opening)
                             (Jaw opening)
                                                                                                 (Jaw opening)
           Oil volume required 50 cc         Reservoir Capacity 53cc           Oil volume required 77 cc
            Force at die face  106kN          Force at Die Face 127kN           Force at die face 118 kN
                  Size       340 (L) mm             Size       290 (L) mm             Size       420 (l) mm
      www.specialisedforce.com.au
                Weight       4.75kg               Weight       6.2kg                 Weight      5.7 kg
          FEATURES                           FEATURES                          FEATURES
          The EP-431HA is a remote           Designed for high durability      The EP-510HE is a remote
          C-head that requires an            industrial use. The EP-410HF      C-head that requires an
          external 700 BAR or 10,000 PSI  is suitable for industrial cable     external 700 BAR or 10,000 PSI
          pumping source for operation.      assembly. It has more than        pumping source for operation.
                                             double of life cycle compared
          This tool was designed to                                            The larger jaw opening of 42mm
          accommodate 12 ton dies for        with model EP-431HA with          accepts conductors and mid-span
          applying compression fitting to    10-15k+ of crimps expected.       sleeve connections.
          copper, aluminium, and ACSR        The EP-410HF is a hydraulic
          conductor.                         compression head for lugs and     The tool was designed to
                                                                               accommodate industry standard
                                             connectors up to 300mm2.          dies for applying compression
                                             DETAILS                           fittings to copper, aluminium, and
                                                                               ACSR conductor.
                                             • Dies are sold separately.
                                               Refer page 18–20
                                               for 12T dies

                         • Refer page 116–117 for hydraulic coupling configurations and hoses,
                               supplied standard with screw type female 3050-3 coupling
                                • Dies are sold separately, refer page 18–20 for 12T Dies
                                    • Battery or Electric pumps, refer page 106–112
