DERAILERS – HINGED

HINGED DERAILERS (FOR RAIL 36-64KG) (MADE IN USA)

For more convenience and greater safety, Aldon now offer a Pop-
Up sign holder for our hinged derails.
NEW
POP-UP The weight of the derail block when swung on the rail causes the
SIGNS sign holder to rise. When the derail block is swung off the rail the
sign holder falls down to the sleepers.
Two-Way Freight Car Derail is shown in use with Pop-Up sign
holder and optional lifting lever.

MODEL NO. 4014-13

Model No. 4014-13 LOCOMOTIVES & RAIL CAR STOPPING DEVICES

Adapter Plate for Installing Hinged Derails on steel sleepers
Track. steel adapter plate, 25.4mm thick is welded to three
Description steel sleepers. Custom-sized derail is bolted to plate. Plate
accommodates all types of rail clips. The adapter plate is
custom made and is not returnable.
Wt (kg) 114.0

MODEL NO. 4014 SERIES
SideKick Derail Booster is designed for hinged derails. Use
sidekick Derail Booster wherever additional derailing capability
is needed. sidekick is useful in curved track where the derail
has to be located on the inner curved rail. In such a situation,
by placing the sidekick on the outer curved rail, the derailing
capability is enhanced.
For more information on the problem of derailing in curved
track, see page 123.
sidekick is installed opposite a hinged derail on the same two
sleepers. Like a hinged derail, sidekick folds down between the
rails when not needed.
NEVER use a SideKick alone. It should always be used in conjunction with the Aldon hinged derail
model specified at the right. Workers must ensure that the derail and the SideKick are both in the
same position (on or off the rail) at all times.
sidekick works with a derail to give an extra boost to assure derailing by guiding the wheels of a car or
locomotive off both rails.

TWO-WAY FREIGHT CAR sIDEkICk DERAIL www.specialisedforce.com.au
sIDEkICk DERAIL BOOsTER
BOOsTER
Model No. Throw Wt (kg) Model No. Throw Wt (kg)
4014-15 Left 59 4014-17 Left 59
4014-16 Right 59 4014-19 Right 59
