WINCH – PULLER ELECTRIC

ELECTRIC CABLE PULLERS (CONTINUED)

Model No. 31466 00369 03196 00812 00814 00813 00829 MVB
Max 28.9 35.8 35.6/44.5¹ -
Pulling Force (kN)
Continuous 20.0 28.9 28.9 -
None/5.0 None/2.7 None/4.9 -
8.9/3.4
8.9/4.3
8.8/3.4
Pulling speed Load / Metres per 17.9/2.3 17.8/2.3 17.8/3.6 - -
Minute
26.7/1.8 26.7/1.8 26.7/2.1 -
- - 35.6/1.83 -
Drive Motor (kW) 1.1 1.1 1.1 -
Rope*(mm OD/kN) 19.1/115.6 22.2/142.0 22.2/142.0 -
Length 527 292 813 1194
Dimensions - Main Motor ELECTRICAL, WINCHES, STRINGING & CABLE LAYING
Unit (mm) Width 572 660 305 1067
Height 305 215 305 1219
Tugger Weight (kg) 49 39 49 146
- - Force Gauge P P P P P P P
00865 00865 Floor Mount P P
02846 02846 Chain Mount P P P
00870 00870 Wheeled Carriage P
versiBoom Package P P P
NOTE: Winch Model 31466 Optional Floor Mount Available (Use Model No. 35605)
* Rope is a critical link in pulling operations, use only manufacturer recommended double braided composite rope.
¹ Momentary maximum pull force of 44.5kN. For 28.9-35.6kN this is achieved with machine 15 minutes on, 15
minutes off. PROUDLY MARKETED, SERVICED
² Two speed motor, values are for high speed. On low speed 26.7kN = 2.13m and 35.6kN = 1.83m.
³ Contact us for details of the parts of the versiBoom kit for UT5 & SUPPORTED AUSTRALIA WIDE

Model No. 00813 SCAN
& PLAY

REFER PAGE
229 FOR
MODULAR www.specialisedforce.com.au
SAFETY
Model No. 00814 BARRIERS
