PORTABLE CAPSTAN WINCH – ROPES & ROPE CASES/BAGS –
PORTABLE WINCH
PORTABLE CAPSTAN WINCH –
ROPES & ROPE CASES/BAGS

DOUBLE BRAIDED POLYESTER ROPES

PCA-1203M2ESC PCA-1213M2ESC PCA-1214M2ESC PCA-1216M2ESC PCA-1218M2ESC

Minimum Breaking Roll Dimensions (L x
Model No. Rope OD (mm) Length (m) Weight (kg)
strength (UTs) (kg) OD)
PCA-1203M2ESC 10 100 2200 100m x 10mm 8.3
PCA-1213M2ESC 12 100 3300 100m x 12mm 14
PCA-1214M2ESC 12 150 3300 150m x 12mm 20.4 ELECTRICAL, WINCHES, STRINGING & CABLE LAYING
PCA-1216M2ESC 12 200 3300 200m x 12mm 25.5
PCA-1218M2ESC 12 300 3300 300m x 12mm 36.6
NOTE: All ropes include soft eye splices on each end. UTs = Ultimate Tensile strength. suggested safety factors
(check local standards or guidelines): Pulling 3:1 / Lifting 5:1.
CASES AND ROPE BAGS

PCA-0100 PCA-0102 PCA-0104 PCA-0105 PCA-1630 PCA-0340 PCA-0350

Model No. Description Material Length (cm) Width (cm) Height (cm) Weight (kg)
PCA-0100 Purpose built transport case with moulded locations for models High-Impact 66 58 41 8
PCW5000 or PCW5000-Hs and many accessories. Plastic
Purpose built transport case with moulded locations for the High-Impact
PCA-0102 47 44 33 4.8
PCW3000. Fits moulded Backpack PCA-0104. Plastic
Moulded Backpack for Transport Case PCA-0102 and Rope Bag
PCA-0104 Polymer 40 18 54 1.8
PCA-0103 or XXL Extra Large Transport Bag PCA-0105
XXL Extra Large transport bag (50 litres). Fits moulded Resistant
PCA-0105 26 24 17 1
backpack PCA-0104. vinyl
PCA-1630 Waterproof and airtight case with removable casters and folding Polymer 79.5 61.5 44.4 15.1
top handle for PCT1800 or PCH2000 winches and accessories.
Waterproof and airtight case with removable casters and folding
PCA-0340 Polymer 58 58 56 14.8
top handle for winches and accessories.
Waterproof and airtight case with folding side handles for
PCA-0350 Polymer 57 57 53 13.9
winches and accessories. www.specialisedforce.com.au

PCA-0103 PCA-1255 PCA-1256 PCA-1257XL

Model No. Feature Material Diameter (cm) Height (cm) Weight (kg)
PCA-0103 Rope Bag - For Backpack PCA-0104. Will store 50 Resistant vinyl 30 38 0.6
metres of 10 mm rope.
Rope Bag – small - Two handles. Will store either 50
PCA-1255 metres of 12 mm rope or 100 metres of 10 mm rope. Durable Nylon 26 36 0.5
PCA-1256 Rope Bag – Medium - Will store either 100 metres of 12 Durable Nylon 26 61 0.9
mm rope or 200 metres of 10 mm rope.
Rope Bag – Extra Large - Will store either 200 metres of Durable Nylon with
PCA-1257XL 37 59 2.06
12 mm rope or 400 metres of 10 mm rope. Hard Bottom
