RAIL DRILL – HYDRAULIC – TRAK-STAR
RAIL DRILL – HYDRAULIC

HYDRAULIC RAIL DRILL (MADE IN USA)

MODEL NO. RM42

DRILLS, SAWS & IMPACT WRENCHES
Put less work into your rail drilling with the Power Feed
RailMaster Hydraulic Rail Drill. It can drill up to a 43mm holes SCAN
TM
using the easy to install Twister Bits in standard rail & PLAY
TM
in 28 seconds and less than 35 seconds in fully heat
treated rail. The drill operates at 19 LPM / 138 Bar with
a 3kW/4HP motor, while weighing just 21.8kg. The
TM
RailMaster provides high clamping forces, and is easy
to carry and operate by one person. A simple forward/
reverse lever turns the quill feed arbor on or off. Plus it
TM
has place holders for extra Twister Bits . Clamps are
available for drilling crane or girder rail.
FEATURES
• Hydraulic Power Feed Motor with Forward & Reverse
• Weighs only 21.8kg
• Uses Twister Bits™
• Accurate quill-Feed Arbor system
• Positive slug Ejection
• RPM 150
• Thru-the-Tool Cooling • 2 Place Holders for extra Twister Bits™
• 10 Point Clamping system • Drill Holes in less than 28 sec.
• suitable for drilling bonding holes • Optional clamp for crane/ girder rail
• quick Change Rail shoes • One Year Warranty
• Centre Balanced Handle • Clearance for concrete sleepers
SPECIFICATIONS

Rail Capacity
Model No. Power Option Description Motor RPM Max. Hole Ø Unit Wt (kg)
(kg)
www.specialisedforce.com.au
RM42 Hydraulic High Torque 3kW/4HP, 150 43 32-68 21.8
138Bar @
quill Feed
19LPM
OPTIONS & ACCESSORIES (REFER PAGES 7–9)

Rail Shoes Retrofit Kits Bonding Twister Bits Coolant Coolant & Storage Case
Lube
Bottle

Model No. Description
27557 Clamp for Crane Rail (Must use 50mm (2”) Depth
of Cut Twister Bits)
Q8047KIT Girder Rail Retrofit Kit
Q8047B Girder Rail shoe (RI57/R10)
07495 Holder for 50mm Depth of Cut Twister Bits
03540 storage Case - steel
