BATTERY CRIMPER –
        12T IN-LINE





           IN-LINE BATTERY HYDRAULIC CRIMPERS
           (MADE IN JAPAN)

           MODEL NO. SL SERIES

           The Izumi SL slimline series hydraulic crimpers were designed for
           crimping in tight spaces such as switchboards and panels or pre-existing
           cable termination points. They accept standard 12 tonne “C” or “U”
           compression dies. Despite their lightweight “in-line” compact design,
           their performance is still equivalent to that of the pistol style REC-6510.
           The number of times crimping can be completed has increased by
           40% just with the battery alone (BP-80LI when compared to the REC-5
           Series’s BP-80).

           To order complete kits with tool, two batteries, 12VDC-230VAC charger
           and carrying case - use “Kit Model No.” in tables below (suffix “BB”).
      A   CABLE CRIMPING  • The SL-510 is the latched head   • Number of times cutting at full   SL-C510  SL-510
           FEATURES
                                              with press charge indicator
             version of the SL-C510
           • Compress conductors up to
                                              charge: Increased by 40% (when
             400mm²
                                              compared with the REC-5 Series)
           • Rapid ram advance mechanism
                                            • 12VDC-230VAC charger included
                                              with carrying case (“BB” kit
           • Right or left handed operation
                                              models)
           • 180° swivel head (SL-C510)
                                            • Sliding pin with lock function
           • Quality backed by ISO9001
                                              prevents head from opening
           • 14.4VDC 3.0Ah
                                              accidentally
             Lithium-Ion Batteries






      www.specialisedforce.com.au
                  SL-510       LED LIGHTS    SL-C510                             “C” Crimp     Latched Head
           TOOL SPECIFICATIONS                                                     Head


                                                          Capacity (mm2)  Approx Crimps        Reservoir   Wt Inc
                                         Jaw Opening  Force                          Dimensions
            Kit Model No.  Style  HeadType                             per Charge Max          Capacity   Battery
                                           (mm)     (Kn)    Al    Cu      Capacity     (mm)      (cc)     (kg)
           SL-C510(BB)  In-Line    C        42      120    300    400       60      521x150x101  153      7.30
            SL-510(BB)  In-Line  Latched    42      120    300    400       60      485x121x101  153     5.90
           * For special lugs, connectors or sleeves contact Specialised Force as we can test crimp
           materials and suggest most suitable models
           Refer page 10–11 for battery and charger details
           Refer page 18–20 for 12 tonne dies
