OMAC STRINGING MACHINERY SELECTION – OMAC
OMAC STRINGING
MACHINERY SELECTION

OVERHEAD STRINGING MACHINERY (MADE IN ITALY)
ELECTRICAL, WINCHES, STRINGING & CABLE LAYING
Suitable for overhead stringing applications in utility (Transmission
and distribution lines, etc) and associated industry such as
telecommunications and railway. More machines available upon request. Some features and
performances of machines are able to be modified on request.
Performances of machines listed are without optional devices, at sea level at a temperature of 20ºC. Dimensions
and weights are also without optional devices. Information may change without notice due to continual research,
development and improvement. Images and drawings are indicative only.

MACHINE FEATURES
Inclusive Reel Winder Direct Force Readings
Option of having the reel winder Force readings do not rely on Precise Measurement
included as part of the machine which unreliable sources such as hydraulic specialised equipment for accurate
eliminates the need for additional circuit pressure speed and distance measurement
equipment hoses and transportation
Capstan OD Max Rope Power Page Ref
OMAC Model No. Type (mm) (mm) (kW) # Capacity (kN)
F 280.40.P PULLER 325 13-16 26.0 F61 40
F 200.AF.45.2 PULL/TENsIONER 1200 16 65.0 F62 45
F 200.AF.75.2 PULL/TENsIONER 1200 18 77.0 F63 75
F 120.AF.45.2 PULL/TENsIONER 1500 16 65.0 F64 45
www.specialisedforce.com.au
F 200.AF.90.2 PULL/TENsIONER 1200 18 105.0 F65 90
F 120.AF.90.2 PULL/TENsIONER 1500 18 105.0 F66 90
F 120.AF.150.42 PULL/TENsIONER 1500 4X32 175.0 F67 1x150/2x75
F 105.150.22 PULLER 650 2x28 215.0 F68 150
F 120.150.42 TENsIONER 1500 4x40 64.0 F69 2x75

OMAC HISTORY
Established in 1954 by Mr. Luigi Consonni OMAC now consists of two companies; OMAC s.n.c. designs, produces
and commercialises a huge range of machines and equipment suitable for overhead stringing and underground
pulling or stringing conductors, wires, cables for electrical utilities, telecommunications and railways.
The specialisation of OMAC products includes the stringing of overhead transmission lines as well as the laying
of underground conductors, high and low tension, copper and aluminium conductor, as well as the optical fiber
(OPGW). OMAC’s experience and flexibility of production allows them to customise machines for special purposes,
designed on the specific needs and requirements of the customer.
The large number of OMAC machines working today in many countries worldwide is a testament to their
reliability and quality.
Over 40 years of experience in manufacture!

SCAN
& PLAY

MORE MACHINES AVAILABLE UPON REQUEST
For Wire Ropes, Reels and Drum Stands refer to SF Electrical Catalogue
