ROPE – INSULATING

INSULATING ROPE

DETAILS

Red water repellent three strand insulating high tenacity Polypropylene Monofilament fibre rope with low water
absorption coefficient. For hot stick and bare hand work in overhead or substation applications that require
maximum insulating properties. Dry tested at 100,000V per 300mm under humid conditions.
• Quality manufactured (Under ISO 9001) in accordance with IEC 62912.
• Manufactured in various lengths with diameters ranging from 6mm to 20mm.
• Splicing available upon request* F OVERHEAD CONSTRUCTION & STRINGING EQUIPMENT
• Can be manufactured in Safety Yellow
PLEASE NOTE: Made to Order (Safety Yellow) will be subject to longer lead-times.
SPECIFICATION

Rope Size Length (m) Breaking Load Weight per/m
Model No.
(mm) OD on Roll (daN)* (g) Approx
982020 8 100 911 30
982019 8 200 911 30
982018 8 300 911 30
982022 14 100 2847 90
982023 14 200 2847 90
982024 14 300 2847 90
988630 16 100 3416 120

*NOTE: Splicing may reduce the strength of the rope, only qualified personnel should splice this rope as per the
manufacturer’s recommendations. Contact us for more information on approved methods.

APPLICATIONS www.specialisedforce.com.au
For works on high voltage, live line or proximity to electrical line.
Stringing and Laying: Aerial, Optical Fiber, Subterranean.
FEATURES

• Raw material: Polypropylene Monofilament • Spliceable
• Specific gravity: 0.93 • Additive treatment
• No water uptake • Insulating
• Floatability • Excellent Dielectric properties
• Low flexibility • Supplied with quality certificate
• Weak resistance to UV exposure • Manufactured in accordance with IEC 62192
CAUTION
We recommend keeping the rope clean and dry in order to assure the highest dielectric properties.
If the material is not used in good conditions, the highest dielectric protection can not be assured.
