HOOK – LIFTING , AUTOMATIC – GIGASENSE
HOOK – LIFTING , AUTOMATIC

AUTOMATIC LIFTING HOOK (MADE IN SWEDEN)

MODEL NO. IS SERIES

This new concept saves time and increases safety. Lifting operations with mobile cranes
and industrial hoists can safely be managed by the operator alone. The operator can
remain at the controls during lifting and release operation.
FEATURES

SCAN
• Automatically hooks up, safety locks and releases & PLAY
• The risk for injury is dramatically reduced
RAIL MATERIAL HANDLING
• No climbing or assistance required
The GIGASENSE IS Hook consists of hook, housing and link. SCAN FOR IN-USE VIDEO
Forged hook, housing and link are of high-grade alloy steel.
Unloaded, the spring loaded hook is pulled up against the housing in an open, ready-to-
load position where it can easily be hooked onto a lifting eye or other attached hardware.

NOTE: SLINGS ARE NOT RECOMENDED FOR USE WITH AUTO-LIFTING HOOK
1. When the GIGASENSE IS Hook is engaged, the load tension closes the hook and the safety latch is
automatically locked.
2. The hook remains safety locked even if it is unloaded. It is therefore possible to safely set down the load and
make sling adjustments.
3. To release the safety lock after completed lifting operation, the hook is lowered until the upper link has tilted
approximately 60° in relation to the housing.
4. When the lock is released, the hook swings up into an open starting position.
5. The load is released, and the hook is ready for a new lifting operation.

LOWER
HOOK UP After completed lifting operation the
Lifting eye or sling. GIGASENSE IS Hook is lowered until it tilts
into release position and opens.
LIFT RELEASE
When the GIGASENSE IS Hook is engaged, The GIGASENSE IS Hook automatically frees
the load tension automatically safety locks itself from the load and is ready for the next
www.specialisedforce.com.au
the hook and housing assembly. lifting operation.

The Hook is tested and approved by the Swedish Institute
for Materials Testing.
Available in 6 sizes from 1.6 - 21.6 tonnes. Easy to operate,
has rugged design and a high reliability.
Applications include but are not limited to; Blasting mats,
pipes, pumps, machines, gas bottles and general lifting.

Transport Case and a list of spares are available upon request.
Please contact your nearest Specialised Force branch for more information.
SPECIFICATIONS

WLL (Tonne) Locking Dimensions (mm)
Model No. Type Safety Factor Force A B C D E F G Wt (kg)
5:1 (kg)
300159 IS-2 1.6 40-50 310 280 60 340 80 20 42 3.0
300165 IS-5 4 50-70 360 325 50 430 90 32 67 6.7
300161 IS-10 8 200-250 490 425 65 580 110 44 58 15.0
300162 IS-15 12 500-700 525 460 80 625 115 54 72 24.0
300163 IS-20 16 600-800 580 500 80 700 130 65 83 37.0
3001515 IS-27 21.6 500-1500 608 530 100 725 125 Lock 175 Release 65 92 37.0
